Piano Door Hinge

Quality classification under EN 15570, Level 3
For door thickness 15 - 24 mm
Cup depth 12.8 mm
Integrated overlay adjustment +2 mm / -2 mm
Integrated depth adjustment +3 mm / -2 mm
Height adjustment at mounting plate
Steel, nickel plated

Model No.: MWZ02023201
Materials: Stainless Steel
Finish: Primary Color
Specification: 25/30/38/50/75
Specification: 315 °
Quality grade: Comply with ANSI/BHMA A156.9、ASTM-B117（Durability：50000cycles, NSS:48H）
Product features: Smooth and quietness, Strong loading capacity

Get Quotation of this Product

Get Testing Report

ORDER INFO

INSTALLATION DIMENSION

INSTALLATION DIAGRAM
